Volkswagen Atlas P0672: Cylinder 2 – Glow Plug (Circuit)

P0672 Volkswagen Atlas

P0672 is a common diagnostic trouble code found in diesel engines.  It’s generic, which means it has the same definition for the Volkswagen Atlas as it would any other vehicle.

P0672 indicates that your Atlas’s second cylinder glow plug is not working.  This code is typically caused by a bad glow plug or wiring issue.  We cover troubleshooting steps in detail below.


P0672 Definition

P0672 Definition: Volkswagen Atlas

Here’s the definition of P0672:

Cylinder 2 Glow Plug

Diesel engines don’t use spark plugs. Instead, they uses glow plugs to preheat the combustion chamber.

Glow plugs heat up the combustion chamber before your Atlas starts. The “glow plug” light lets you know that they are doing their job.  Once the vehicle is started, the heat and compression generated through diesel combustion are enough to keep the engine running (diesel engines have higher compression ratios than gas-powered motors), and the glow plugs are turned off.

The Volkswagen Atlas’s PCM (powertrain control module) uses data from the engine and transmission temperature sensors to determine if the engine is cold enough to warrant the use of the glow plugs.

They’re usually only needed when a diesel engine has been sitting for a while.  It wouldn’t cool off enough while fueling up, for instance.  That’s why the symptoms of P0672 are usually only felt when the vehicle is cold started.

Circuit

In the case of P0672, the code means that the circuit that provides power to the second cylinder’s glow plug is faulty.  That’s it.  It doesn’t specify if it’s open, short, low, or high voltage.


P0672 Symptoms:  Volkswagen Atlas

If your Volkswagen Atlas has P0672 there are likely to be some noticeable symptoms.  Although one bad glow plug is usually not enough to bring a modern diesel engine down.

  • Check engine light with P0672
  • Hard start
  • Misfiring (Until the second cylinder warms up)
  • No start
  • Low engine power until the engine warms up
  • Diesel fuel smell from exhaust

If the engine starts, let it idle and build heat before driving it.  You want enough heat in there that cylinder 2 starts to fire on its own.  While your Atlas may run and drive ok once it’s heated up, it’s still dumping unburned fuel into the exhaust until cylinder two starts firing.

With most diesel engines, having one glow plug out will not be enough for it not to start.


Volkswagen Atlas P0672 Diagnosis + Causes

P0672 Diagnosis

While P0672 refers to a circuit issue, it also can be caused by a bad glow plug as well.  Here’s how to diagnose this code in your Volkswagen Atlas:

1. Determine if the glow plug is bad

There are a few ways that you can tell if the glow plug is functioning properly.  If they are easy to get to, you can do the “swap test.”

Remove the glow plug from the second cylinder.  Then, swap it with another glow plug (whichever is easiest to access).  Once you do that, use your scanner to clear the OBDII memory.

Make sure your Atlas is cold, go ahead and fire it up. Wait for the check engine light to come back on.

If the code stays P0672, you know there is a wiring issue, you’ll need to troubleshoot the harness.

If the code changes to P067X (X being the cylinder with the bad glow plug), replace the glow plug with a new one, and you’re done.

You can also use a test light to determine if a glow plug is bad. Here’s how to do it.

2. Check the Wiring Harness

Now that you know your Atlas doesn’t have a bad glow plug, it’s time to check the wiring harness.

Check it for damage (think cracked wiring, bad ground, or loose connection at the glow plug).  The glow plug wiring harness has fusible links, so if the harness is hot on one side of the link, but not on the other, you’ll need to replace it.

If it all looks fine, you’ll need to get an OHM meter and check the resistance at the glow plug.  You’ll need to look up the wiring diagram for the exact engine and model year of your Volkswagen Atlas.


Conclusion

P0672 is usually pretty easy to track down.  Good luck fixing your Atlas!
